Introduction

Introduction

Our automatic watch winder was engineered for automatic watch collectors and enthusiasts , it is a device which holds a watch (or often more than one) and moves it in a circular patterns to emulate the necessary parts of human motion to operate the self-winding mechanism. When the watch is not worn, just put it on our watch winder, with the electronic digital technics, it will wind your watches automatically while power on, and thus will save your troubles from re-setting when needed. It is also equiped with adjustable cushions to suit different size of watch bands.



Operation Instruction

Step 1 C Load your watches in cushions.cushions size are adjustable by taking out the outside belt.

Step 2 C Plug in the adapter and turn on power






Power Switch and Adapter Socket are in the rear of Watch Winder

Switch (on/off)   Adapter Socket           Adapter (O/P:DC3V,1.5mA)




















Step 3 - Select programs by Knob switch, 5 models available.



Knob Switch


















Note: The green LED light will turn on during operation . The LED light will turn off after the winder finishes winding



Programs Details

Mode 1, Operation On/Off.
Mode 2, Turn clockwise. Rotate for 2 minutes and rest for 6 minutes and then repeat.
Mode 3, Turn counter clockwise. Rotate for 2 minutes and rest for 6 minutes and then repeat.
Mode 4, Turn both clockwise and counter clockwise. Rotate for 2 minutes in one direction and then rest for 6 minutes. Rotate for 2 minutes in the opposite direction and then rest for 6 minutes. Repeats above cycle.
Mode 5, Turn both clockwise and counter clockwise. Rotate for 5 minutes in one direction and then rotates in opposite direction in same 5 minutes. Repeats continuously for 3 hours and then rests for 9 hours. After 9th hour, it will begin rotating above cycle.



Warning

1- Please do not manually spin the rotator. This will damage your watch winder warranty

2- Please use the adaptor included in your watch winder package or with exactly same voltage output

adapter as below:I/PAC100-240V50/60Hz0.2A  O/P:DC 3V,1.5mA
